Forging production line

The numerical control electric 1000T screw press has high impact accuracy, good product consistency and high forming accuracy, which can meet the demanding requirements for forgings.

Metal processing production line—CNC machine tools

The production line adopts a large number of numerical control processing technology, with stable processing quality, high processing accuracy, high repeatability, and high efficiency and automatic processing. There are 30 CNC lathes, 20 CNC vertical milling machines, 5 digital display horizontal boring machines, and 3 CNC broaching machines.

Gold processing production line—Broaching machine

Used for processing the inner hole of the press ring. The production efficiency is high, the processing quality is good, the consistency is strong, the accuracy is generally IT9-IT7, and the surface roughness Ra value is 1.6-0.8um. However, since the broach of a broaching machine can only process one size surface, and the broach is relatively expensive, the broaching machine is mainly used for mass production.

Heat treatment production line

The pit type gas carburizing furnace is a new type of energy-saving cycle-operating heat treatment electric furnace, which mainly performs gas carburizing on steel parts. This series of carburizing furnaces have uniform furnace temperature, fast heating, and good heat preservation. The workpiece carburizing speed is accelerated, the carbon potential atmosphere is uniform, and the carburizing layer is uniform. When the furnace pressure is increased, there is no leakage, which improves the production efficiency and carburizing quality.

Spray production line

The design of the full-line system of the spray production line refers to foreign design concepts and parameters, no thinner materials are required, construction is non-polluting to the environment, and non-toxic to the human body; the coating has excellent appearance quality, strong adhesion and mechanical strength; spray construction has a short curing time; The layer has high corrosion resistance and wear resistance, which can bring better surface quality to the oil press.

Oil press assembly production line

Fast Carbon Silicon Analyzer in Front of Furnace

It can detect the carbon equivalent CEL, carbon percentage, silicon percentage, pouring temperature TM, liquidus temperature TL, and solidus temperature TS in raw molten iron such as gray iron, ductile iron, malleable iron, vermicular iron.

Metallographic analyzer

Accurately and objectively analyze the matrix structure, impurity content, and tissue composition of metals or other materials to provide a reliable basis for product quality, which can make enterprise quality control more scientific and improve the level of enterprise management. It is engaged in new product development , An effective tool for product quality monitoring. It can quantitatively analyze the percentage of pearlite, ferrite, etc., measure grain size determination, phase area percentage, coating (carburized layer) and coating thickness measurement, porosity evaluation, and spheroidization of graphite in ductile iron , Particle size and number of grains, weld depth measurement, fiber diameter measurement.
